BLRCS250A300B40
SKU: TR
$43.59Price
BLRCS250A300B40 - SCHNEIDER
EasyCan Capacitor - 25/30 kvar - 400 V - 50/60Hz
In Stock
Description
EasyCan capacitor are designed to work in slightly polluted netwroks with Detuned reactors. These capacitors are used for standard operating conditions, and when no significant non-linear loads are present. These capacitor are the right choice to maximize the savings in an electrical system which is stable. This capacitor provides a rated output power of 25 kVar at 400V AC, 50 Hz. Fastening assured by a ClampTite terminal. This component meet the standards IEC 60831-1 and IEC 60831-2. The case product weight is 2.3 kg.
Specifications
product or component type Standard duty capacitor Network frequency 50/60 Hz Series name EasyLogic PFC Capacitor Network harmonic content <= 10 % Electrical parameters 22.6 kvar 380 V 50 Hz
27.1 kvar 380 V 60 Hz
25 kvar 400 V 50 Hz
30 kvar 400 V 60 Hz
26.9 kvar 415 V 50 Hz
32.3 kvar 415 V 60 HzMaximum permissible voltage 1.1 x Un (8 hours over 24 hours) continuous overcurrent capacity 1.5 x In Rated voltage 380…415 V AC 50/60 Hz Complementary
Dielectric losses < 0.2 W/kvar Power losses < 0.5 W/kVAr capacitance tolerance - 5 % to 10 % Voltage test 2.15 x Un AC between terminals for 10 s
<= 660 V - 3 kV AC between terminal and container for 10 s
>= 660 V - 6 kV AC between terminal and container for 10 sInrush current 200 x In Maximum switching operation per year 5000 Service life in hours 100000 h Dielectric material Metallized polypropylene film with Zn/Al alloy, Impregnation material Non-PCB soft PUR resin
BiodegradableType of installation Indoor installation Connections - terminals ClampTite terminal Mounting mode Vertical Diameter 90 mm Height 308 mm net weight 2.3 kg Environmental
Standards IEC 60831-1
IEC 60831-2IP degree of protection IP20 Operating altitude 2000 m Temperature class D Ambient air temperature for operation -25…55 °C Relative humidity 95 %
