LA1KN13

LA1KN13

SKU: TR
$5.15Price
LA1KN13 - SCHNEIDER
Auxiliary contact block, TeSys K, 1NO+3NC, front mounting, screw clamp terminals
In Stock
Description
TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals (except LP4K, LP5K, CA4K). It provides 1NO+3NC contacts rated up to 10A 690V AC, connection by screw clamp terminals. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh).
GTIN: 3389110500134
Quantity

  • Specifications

    Range TeSys
    Product name TeSys K
    Product or Component Type Auxiliary contact block
    Device short name LA1
    Range compatibility TeSys K LC1K
    TeSys K CA2K
    TeSys K CA3K
    Mounting Location Front
    Pole contact composition 1 NO + 3 NC
    Contacts operation Instantaneous
    [Ue] rated operational voltage 690 V AC 25...400 Hz
    [Ui] rated insulation voltage 690 V IEC 60947-5-1
    600 V UL 60947-5-1
    600 V CSA C22.2 No 60947-5-1
    [Ith] conventional free air thermal current 10 A (at 122 °F (50 °C))
    Standards EN/IEC 60947-5-1
    UL 60947-5-1
    CSA C22.2 No 60947-5-1
    GB/T 14048.5
    JIS C8201-5-1
    Product Certifications CB Scheme
    CCC
    UL
    CSA
    CE
    UKCA

  • Complementary

    Irms rated making capacity 110 A at <= 690 V AC conforming to IEC 60947
    Permissible short-time rating 80 A 1 s
    60 A 500 ms
    110 A 100 ms
    Associated fuse rating 10 A gG at <= 690 V conforming to IEC 60947
    Minimum switching current 5 mA
    Minimum switching voltage 17 V
    Non overlap distance 0.02 in (0.5 mm)
    Insulation resistance > 10 MOhm
    Connections - terminals Screw clamp terminals 1 0.00…0.00 in² (0.34…1.5 mm²)flexible with cable end
    screw clamp terminals 1 0.00…0.01 in² (0.75…4 mm²)flexible without cable end
    screw clamp terminals 1 0.00…0.01 in² (1.5…4 mm²)rigid
    screw clamp terminals 2 0.00…0.00 in² (0.34…1.5 mm²)flexible with cable end
    screw clamp terminals 2 0.00…0.01 in² (0.75…4 mm²)flexible without cable end
    screw clamp terminals 2 0.00…0.01 in² (1.5…4 mm²)rigid
    Tightening torque 11.51 lbf.in (1.3 N.m) Philips No 2
    11.51 lbf.in (1.3 N.m) pozidriv No 2
    Height 1.18 in (30 mm)
    Width 1.50 in (38 mm)
    Depth 1.38 in (35 mm)
    Net Weight 0.10 lb(US) (0.045 kg)

  • Environmental

    Environmental characteristic Normal environment
    IP degree of protection IP20 conforming to IEC 60529
    Protective treatment TC IEC 60068
    Ambient Air Temperature for Storage -58…176 °F (-50…80 °C)
    Ambient air temperature for operation -13…122 °F (-25…50 °C)
    Operating altitude 6561.68 ft (2000 m)
